6061 Large Diameter Aluminum Alloy Tube
1. Material Composition & Manufacturing Process 6061 aluminum alloy (ASTM B241, AMS 4025) large diameter tubes feature a balanced magnesium-silicon composition optimized for structural integrity and fabrication flexibility: Alloy Chemistry: Magnesium (Mg): 0.8-1.2% (solution strengthening) Silicon (Si): 0.4-0.8% (precipitation hardening) Copper (Cu): 0.15-0.40% (enhanced machinability) Chromium (Cr): 0.04-0.35% (grain refinement) Base Material: Aluminum (Al): ≥97.5% […]
7050 Large Diameter Aluminum Pipe
1. Material Composition & Manufacturing Process 7050 (AMS 4050M, ASTM B247) large diameter pipes feature copper-zinc-magnesium alloying system optimized for high-strength structural applications: Alloy Chemistry: Zinc (Zn): 5.7-6.7% (primary strengthening) Magnesium (Mg): 1.9-2.6% (precipitation hardening) Copper (Cu): 2.0-2.6% (stress corrosion resistance) Trace Elements: Zirconium (Zr): 0.08-0.15% (grain refinement) Iron (Fe): ≤0.15% max Silicon (Si): ≤0.12% […]
2A12 Aluminum Forged Tube for Aerospace
1. Material Composition & Aerospace Forging Process 2A12 (AA2124) aerospace-grade forged tubes comply with AMS 4157, ASTM B247, and MIL-T-9046 specifications, formulated for optimal strength-to-weight ratio in flight-critical components: Alloy Chemistry: Copper (Cu): 3.8-4.9% (primary strengthening) Magnesium (Mg): 1.2-1.8% (precipitation hardening) Manganese (Mn): 0.30-0.9% (grain refinement) Base Material: Aluminum (Al): ≥92.5% (balance) Controlled Impurities: Iron […]
5083 Aluminum Forging Pipe for Marine
1. Material Composition & Forging Process 5083 marine-grade aluminum forging pipes comply with ASTM B247, EN 754-2, and NORSOK M-121 standards with optimized magnesium-manganese composition for seawater corrosion resistance: Primary Alloying Elements: Magnesium (Mg): 4.0-4.9% (enhances strength and corrosion resistance) Manganese (Mn): 0.4-1.0% (controls grain structure) Chromium (Cr): 0.05-0.25% (improves stress corrosion cracking resistance) Base […]
Forged 7075 T6 Aluminum Alloy Pipe
1. Material Composition & Forging Process Forged 7075-T6 pipes conform to AMS 4148, ASTM B247, and ASME SB247 standards, featuring optimized zinc-copper-magnesium composition for ultra-high strength applications: Alloy Composition: Zinc (Zn): 5.1-6.1% (primary strengthening element) Magnesium (Mg): 2.1-2.9% (forms MgZn₂ precipitates) Copper (Cu): 1.2-2.0% (enhances stress corrosion resistance) Base Material: Aluminum (Al): ≥88.0% (balance) Trace […]
1060 Extruded Aluminum Alloy Seamless Pipe
Material Composition & Standards • Conforms to ASTM B241, EN 754-2, GB/T 6893 • Composition: 99.6% Al min. (Fe+Si ≤0.4%) Mechanical Properties • Tensile Strength: 65–95 MPa • Yield Strength: 25–55 MPa • Hardness: 23–32 HV (Hard purity characteristic) Temper Options Tempers: O (annealed), H112 (as-fabricated) Optimal choice: O temper(superior formability) Dimensions & Customization • Size range: OD 10–200 […]
3003 Aluminum Round Tube
Material Composition & Standards • Conforms to ASTM B491, AMS 4007, EN 754-2 • Composition: Mn (1.0-1.5%), Cu (0.05-0.20%), 98.7% Al min. Mechanical Properties (H14 Temper) • Tensile Strength: 150–200 MPa • Yield Strength: 130–180 MPa • Hardness: 40–45 HB Temper Options • Standard Tempers: O (annealed), H14 (strain hardened) • Recommended: H14(optimal balance of formability & strength) Dimensions & […]
6061 T6 Aluminum Tube
1. Material Composition & Standards Conforming to ASTM B210, AMS 4151, and ISO 6361-2 standards, 6061-T6 aluminum tubing features a magnesium-silicon alloy formulation optimized for structural applications: Primary Elements: Magnesium (Mg): 0.8-1.2% (forms Mg₂Si precipitates) Silicon (Si): 0.4-0.8% (enhances strength and fluidity) Copper (Cu): 0.15-0.40% (improves machinability) Base Material: Aluminum (Al): ≥97.0% (balance) Impurity Limits: […]
5052 Aluminum Tubing
1. Material Composition & Standards Conforming to ASTM B210, AMS 4005, and EN 573-3 standards, 5052 aluminum tubing features a magnesium-enriched alloy composition optimized for marine and industrial applications: Primary Elements: Magnesium (Mg): 2.2-2.8% (enhances strength and corrosion resistance) Chromium (Cr): 0.15-0.35% (improves stress corrosion cracking resistance) Base Material: Aluminum (Al): ≥96.8% (balance) Impurity Limits: […]
2024 T3 Aluminum Round Tube
1. Material Composition & Standards Conforming to ASTM B221, AMS 4171, and EN 755-2 international standards, 2024-T3 aluminum round tubes feature a precision-engineered composition optimized for aerospace applications: Primary Elements: Copper (Cu): 3.8-4.9% (forms strengthening Al₂Cu precipitates) Magnesium (Mg): 1.2-1.8% (enhances corrosion resistance) Manganese (Mn): 0.3-0.9% (improves work hardening) Base Material: Aluminum (Al): ≥93.5% (balance) […]
